Description

Cell Overlay Mattress with Pump (Stage II) QDC 501

Cell Overlay Mattress with Pump (Stage II) QDC 501

Technical Parameters Of The Mattress

• Dimensions without flap(L*W*H): 200*90*11cm
• Cell height: 11 cm/ 4.3?
• Number of cells with holes: 8
• Material thickness: 0.36mm
• Cell and base material: Nylon+PVC
• Number of cells: 18+1 Free space cell
• Weight support: 145kg
• Mattress system: Overlay
• Pressure Ulcer Stage: ?, ?
• Warranty: 12months

Technical Parameters Of The Pump (P1000)

• Electrical: AC 110V/220V 50Hz/60Hz
• Pressure: 55-120 mmHg
• Air output: 7-8 Liter/min
• Dimensions(L*W*H): 26.5*13.5*10 cm
• Plastic Casing: Taiwan Chimei ABS
• Test Duration: 24 Hours (Inflation)
• Certificates: TUV-CE IEC/EN60601-1&60601-1-2
• Synchronous Motor: TW Ann Yih Brand
• Cycle time: 12 min
• Warranty: 24 Months
